CPM132-ST6 Meerwasserpumpe für Bootsklimaanlagen

CPM132-ST6 SEAWATER PUMP

CPM 100 ST-6 Specification Value
Warranty 2 years
Voltage 230 V
Power 250 W
Head (min–max) 6.5–15.5 m
Flow rate 10–90 L/min
Inlet connection 1 1/4" internal thread
Outlet connection 1" internal thread
Maximum suction depth 7 m
Max. liquid temperature 90 °C
Pump housing AISI 316L stainless steel
Shaft AISI 316L stainless steel
Mechanical seal AR-12ST6 carbon-ceramic
Impeller AISI 316L stainless steel
Cable length 0 m
Protection rating IP X4
Weight 5.6 kg

Pedrollo CPm 132 ST6 – 1-phase centrifugal pump. This pump is suitable for the circulation of fresh water in MBC Marine cooling systems. It is designed for clean liquids that do not attack the pump materials. It is reliable and easy to operate and must be installed in a dry, protected location.
